100g-10kg uager filling machine

ModelDCS-5B-1DCS-5B-2Feeding Mode 100g-10kg1-50kgFilling Weight 100-1000g,≤±2g; >1kg, ≤±0.1-0.2%≤±0.1-0.2%Filling Rate 5-30 times/min 5-25 times/min Power Supply 3P AC 208-415V 50/60Hz 3P AC 208-415V 50/60Hz Total Power 2.2kw2.7kwTotal Weight 350kg400kgOverall Dimensions 1000*850*2300mm1100*950*2500mmHopper volume 70L100L Abstract : This model is designed mainly for the fine powder which easily to spout dust and high-accuracy packing requirement .Based on the feedback sign given by below weight sensor, this machine do measuring,. two-filling , and up-down work ,etc. It is specially suitable for filling carbon powder, dry powder of fire extinguisher, and other fine powder which needs high packing accuracy.Characteristics: 1. Weight sensor is below the tray, to do fast filling and slow filling based on the pre-set weight, to guarantee the high packaging accuracy. 2. Servo motor does up-down work driving with tray together, the up-down rate can be set randomly, no dust spouts out when filling. 3. With servo motor and servo drive controlled auger, perform stably, and with high accuracy. 4. PLC control, touch screen display,easy to operate. 5. Made of stainless steel, combined hopper, easily to be cleaned. 6. With handwheel to adjust the height , easy to fill many kinds of weight. 7. With fixed screw installation, the material quality wont be effected.Work Procedure : put bag/can(container) on the machine → container raise → fast filling,container declines → weight reaches the pre-set number → slow filling → weight reaches the goal number → take the container away manually Note: the pneumatic bag-clamp equipment and can-hold set is optional ,they are suitable for can or bag filling sperately.
